FEATURES:
- Meets dimensional requirements of ISO 7241 Series B
- Interchangeable with Parker-Hannifin 60 Series, Snap-Tite 72-Series, Hansen HK-Series, Faster Series ‘HNV’, Aeroquip/Eaton FD45, Stucchi Series IRB/IRBO/IRBX
- Machined components are manufactured using solid bar stock
- Stainless steel balls, retaining rings and springs maximize corrosion resistance and extend service life.
- Steel componentry is plated using ROHS Compliant Trivalent Chrome.
- Steel coupler sleeves are hardened to resist deformation and maximize service life.
- Nitrile (Nitrile Rubber) seals are standard
- Redundant o-ring sealing system with PTFE backup ring
- Valve seals are crimped in place to maintain integrity during excessive flow conditions and pressurized connection.
- Poppet style shut-off valves
SPECIFICATIONS:
| BRAND: | Dixon |
| MATERIAL: | Steel |
| MAXIMUM OUTER DIAMETER: | 2.49″ (63.2 mm) |
| THREAD: | Female NPTF |
| BODY SIZE: | 1″ |
| TEMPERATURE RANGE: | -40°F to 250°F (-40°C to 121°C) |
| BURST PRESSURE: | 16000 PSI (1100 bar) |
| THREAD SIZE: | 1″ – 11-1/2 |
| LENGTH: | 4.13″ (104.9 mm) |
| HEX: | 1-5/8″ |
| MAXIMUM OPERATING PRESSURE: | 4000 PSI (275 bar) |
| WEIGHT: | 1.8 lbs. |
WARNING: This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
