FEATURES:
- Lowest pressure drop motor in the industry
- Highly-efficient Geroler motor provides energy savings
SPECIFICATIONS:
| BRAND: | Danfoss |
| SUB BRAND: | Char-Lynn |
| APPLICATION: | Swing motor, Brush Cutters & mowers, Harvesting equipment |
| BRAKE TYPE: | Hydraulic |
| CASE FLOW OPTIONS: | .4375-20 UNF-2B SAE O-Ring Port |
| DESIGN CODE11: | 6 |
| DISPLACEMENT: | 101.6 cubic centimetre per revolution |
| ECCN: | EAR99 |
| FLOW RATE12: | 75 litre per minute |
| FRONT SEAL KIT IF AVAILABLE: | 61258-000 |
| GEROLER OPTIONS: | Standard |
| ICC2: | Low-Speed Gerotor/Geroler |
| INTERMITTENT PRESSURE: | 310 bar |
| MAXIMUM SPEED: | 742 revolutions per minute |
| MODEL CODE: | M02062AC01AF0100010000000AAAAF |
| MOUNTING TYPE: | Standard, 2 Bolt; 82.6 [3.25] Pilot Dia. 13.59 [.535] Dia. Holes On 106.4 [4.19] Dia. Bolt Circle (SAE A) |
| OUTPUT SHAFT TYPE: | Straight |
| PORT TYPE: | 1.0625-12 UN-2B SAE O-Ring Ports – Ports Oriented 180 Deg To Each Other |
| PRODUCT HEIGHT: | 6.96″ |
| PRODUCT LENGTH: | 9.54″ |
| PRODUCT MATERIAL: | Cast Iron |
| PRODUCT TRADE NAME: | 2000 Series |
| PRODUCT WEIGHT: | 21.00 lbs. |
| PRODUCT WIDTH: | 5.16″ |
| RECOMMENDED SYSTEM WORKING TEMPERATURE: | -34°C to 82°C |
| TORQUE: | 295 newton metre |
| VISCOSITY RECOMMENDATION: | 70 Saybold universal second |
