- Electrical – Current Interrupting – Receptacle certified for current interrupting at full rated current with equivalently rated NEMA® plug
- Electrical – Dielectric Voltage – Withstands 2,000V minimum
- Environmental – Flammability – UL 94 V-2
- Environmental – Operating Temperature – Maximum continuous 75°C, minimum -40°C (without impact)
- Mechanical – Product Identification – Ratings are a permanent part of the device
- Mechanical – Terminal Identification – Terminal wire leads identified in accordance with UL 498
Features
- Audible SNAP, indicates solid connection
- Reduces installation time
- Quick Connect- SNAPConnect, USA Product
- Fully insulated design
Industry Standard(s)
- Certified to CSA, C22.2, No. 42 File 285
- Fed. Spec. W-C-596
- NEMA® WD-6 Compliant
- UL Listed to UL498 File No. E2186
