Model: SG4TMSTD | Series: SG | Product Line: Bolting Tools
- The SG4TM secure grip bolt-hole spreader can be used on all flange types with bolt-hole sizes ranging from 0.69″ (17.5mm) to 0.91″ (23.5mm). Additional short collet holders are supplied within the tool kit allowing the tool to spread flanges apart and remove a spacer, wafer or butterfly valve. This low-end, mechanical model offers up to 4.2 imperial tons (37kN) of spreading force.
- Spreading force of 8.4 imperial tons (74 kN) if used in pairs as recommended.
- Set Includes:
1 x SG4TM Tool
1 x 6″ (150 mm) Vernier Calliper
1 x 3/8″ Drive Torque Wrench and 16 mm Socket
1 x Safety Block
2 x M16 (5/8″) Collets
2 x M20 (3/4″) Collets
1 x Instruction Manual
1 x Carry Case with protective foam inserts - Short Collet Holder Sets (SCH) are available which can offer an improved range of applications.
- Collet Holders can also be dismantled and inserted through bolt-holes from the opposite side.
