FEATURES:
- Lowest pressure drop motor in the industry
- Highly-efficient Geroler motor provides energy savings
SPECIFICATIONS:
| BRAND: | Danfoss |
| SUB BRAND: | Char-Lynn |
| MOUNTING TYPE: | Standard, 2 Bolt; 82.6 [3.25] Pilot Dia. 13.59 [.535] Dia. Holes On 106.4 [4.19] Dia. Bolt Circle (SAE A) |
| OUTPUT SHAFT TYPE: | Straight |
| PAINT: | Primer Low Gloss Black |
| PORT TYPE: | .875-14 UNF-2B SAE O-Ring Ports – Staggered Ports |
| PRESSURE FLOW OPTION: | None |
| PRODUCT HEIGHT: | 4.33″ |
| PRODUCT LENGTH: | 8.99″ |
| PRODUCT MATERIAL: | Cast Iron |
| PRODUCT TRADE NAME: | 2000 Series |
| PRODUCT WEIGHT: | 21.50 lbs. |
| PRODUCT WIDTH: | 5.16″ |
| RECOMMENDED SYSTEM WORKING TEMPERATURE: | -34°C to 82°C |
| TORQUE: | 385 newton metre |
| VISCOSITY RECOMMENDATION: | 70 Saybold universal second |
