FEATURES:
- Durable cast aluminum housing
- Acrylic sight glass
- Baylast™ O-ring and retainer ring
- Low cost sight glass tube can be easily replaced
- Due to the proprietary blending of petroleum products, Dixon recommends that the thermoplastic tubing and the gaskets be immersion tested in the product to be handled to ensure compatibility
- Not compatible with crude oil.
- Maximum flange bolt torque is 200 in-lb (inch pounds)
SPECIFICATIONS:
| BRAND: | Bayco |
| MATERIAL: | Aluminum |
| SEAL: | Baylast™ |
| FUEL COMPATIBILITY: | Gasoline and diesel, up to E100 and B100 biofuels |
| WIDTH: | 1-3/4″ |
| INNER DIAMETER: | 3-1/2″ |
| FLANGE SIZE: | 3″ TTMA |
| WEIGHT: | 1.18 lbs. |
WARNING: This product contains lead, a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
